System error Component/System

01.1:10 Main PCA (MPCA) failure

01.1:19 Incorrect Main PCA installed

01.3:10 Bundle Board failure

02:10 Carriage Board Failure

03.1:10 Battery of Real-Time Clock ran down

08:10 Front Panel does not respond

21:10 Service Station (SS) failure

21.1:10 Pump motor failure

26:10 Ink system failure

27:10 Generic printhead error

41:10 Paper servo error

41.1:10 Right Rear Gear Train (picking motor) failure

41.2:10 Paper/Feed motor failure

42:10 Carriage servo error

42.1:10 Carriage motor failure

45:10 Rewinder motor failure

51:10 Top Cover sensor failure

51.1:10 Ink Cartridge Cover Sensor failure

53.1:10 OOP sensor failure

53.2:10 Output Tray sensor failure

55:10 Line Sensor failure

59.1:19 S/N Mismatch

59.2:19 An unsupported or reused NVM has been installed

79:03 Generic printer error (NVM reseated)

79:04 Generic printer error (FW assert)

85.1:10 Feed Index Sensor failure

85.2:10 Feed Encoder Sensor failure

87:10 Encoder Strip failure

System error Component/System

01.1:10 Main PCA (MPCA) failure

01.1:19 Incorrect Main PCA installed

01.3:10 Bundle Board failure

02:10 Carriage Board Failure

03.1:10 Battery of Real-Time Clock ran down

08:10 Front Panel does not respond

21:10 Service Station (SS) failure

21.1:10 Pump motor failure

26:10 Ink system failure

27:10 Generic printhead error

41:10 Paper servo error

41.1:10 Right Rear Gear Train (picking motor) failure

41.2:10 Paper/Feed motor failure

42:10 Carriage servo error

42.1:10 Carriage motor failure

45:10 Rewinder motor failure

51:10 Top Cover sensor failure

51.1:10 Ink Cartridge Cover Sensor failure

53.1:10 OOP sensor failure

53.2:10 Output Tray sensor failure

55:10 Line Sensor failure

59.1:19 S/N Mismatch

59.2:19 An unsupported or reused NVM has been installed

79:03 Generic printer error (NVM reseated)

79:04 Generic printer error (FW assert)

85.1:10 Feed Index Sensor failure

85.2:10 Feed Encoder Sensor failure

87:10 Encoder Strip failure

01.0 Main PCA/Electronics module

01.1 Add-on Electronics module (printmech)

01.2 Print Mech PCA

02.1 Carriage PCA

02.2 Carriage PCA

03 Power supply

05.1 Fan of the Formatter

06 Formatter

08 Front panel

11 Trailing cable

12.n Carriage flex circuit n to pens

21 Service station

21.1 Service station

22.0 Bongo error BPS0 (ISS Left)

22.1 Bongo error BPS1 (ISSLeft)

24 Tube assembly (IDS)

26.n Ink Cartridge (color = n)

27 Printhead error

31 Cutter

38 Output Tray

41 Paper-axis motor

41.1 Paper-axis motor

42 Scan-axis motor

44 Aerosol fan

45 Rewinder

47 Star wheel motor

48 PPS mechanism

51 Window Sensor

52 Drop detector

55 Line sensor

56 Drive roller analog encoder sensor

61 Error job

62 PC Interface

63 Input/output through LAN card

64 Input/output through USB port

65 Input/output (not known what port)

66 Input/output (not known what port)

67 Input/output through FireWire port

68 Loss of engine counters tracking

71 Memory management

71.19 PrintMech PCA/Formatter

72 Firmware error

73 Servo

74 Firmware upgrade

74.1 Media Profile Update

75.1 Preventive Maintenance kit #1

75.2 Preventive Maintenance kit #2

75.3 Preventive Maintenance kit #3

75.4 Preventive Maintenance kit #4

76 Disk Full

77 Web access application

78 Borderless

78.1 Media Settings

79 Assertion (uncontrolled FW error)

79.1 Recoverable Firmware Error

81 Media advance

81.1 Media advance

84 Roll Feed

85 Media-axis encoder reading

86 Carriage Movement

87 Scan-axis encoder reading

93 Ink Pumping

94 Color calibration

94.1 Profiler

95 Printhead alignment

97 Paper advance calibration
